SPECIFICATIONS
| OZONE OM400 | OZONE OM800 | OZONE OM1600 | OZONE OM3200 | OZONE OM4000 | Capacity | 400 gr/Hr | 800 gr/Hr | 1600 gr/Hr | 3200 gr/Hr | 4000 gr/Hr |
| Overall Dimensions | 100 x 70 x 200 cm | 200 x 70 x 200 cm | 300 x 70 x 200 cm | 400 x 70 x 200 cm | 400 x 70 x 200 cm | |
| Ozone Pump Capacity | 4 CBM/Hr | 8 CBM/Hr | 16 CBM/Hr | 32 CBM/Hr | 40 CBM/Hr | |
| Total Weight | 350 Kg | 450 Kg | 600 Kg | 750 Kg | 900 Kg | |
| Required Power | 4.5 KW | 9.5 KW | 16 KW | 25 KW | 38 KW | |
Supplied System Parts | ||||||
| Specially isolated system with all safety features as per North American Standards | ||||||
| All stainless steel feeding pump | ||||||
| Special Double Air Drying system | ||||||
| Electrical and electronic control panel | ||||||
| Chiller for system cooling | ||||||
| Eleminator/ Converter unit converting the ozone into oxygen after the process | ||||||
Advantages of Ozone System | ||||||
| Fully automated Ozone oxidizing process | ||||||
| Unique, Integrated double air drying system | ||||||
| Secure, sealed system with necessary security features | ||||||
| Controlled process giving repeatable results | ||||||
| Big saving on chemicals | ||||||
| Great savings on Water(hot and cold) | ||||||
| Savings on processing time in the washing machines | ||||||
| Saving on Energy | ||||||
| Tremendous flexibility in design and fashion processes | ||||||
| Full safety including optional ozone leak sensors | ||||||
RESULTS
   | ||
  | ||
    | ||
  |
STRETCH DENIM
   | ||
  |
T-SHIRT
   | ||
   |
